- 61 -
1
) Free Air Delivery (volume flow rate) is measured according to ISO 1217 ed.3 1996 annex D
Tolerance:
• +/- 5% 25 l/s (53 cfm) < FAD < 250 l/s (530 cfm)
• +/- 4% 250 l/s (530 cfm) < FAD
The international standard ISO 1217 corresponds to following national standards:
• British BSI 1571 part 1
• German DIN 1945 Part 1
• Swedish SS-ISO 1217
• American ANSI PTC9
Designation XA(S) 137 DD -
XA(S) 300 DD7
XA(S) 137 DDG -
XA(S) 300 DD7G
XAHS 107 DD -
XAHS 250 DD7
230/400 V (3 phase)
Typical oil content of compressed air mg/m
3
< 5 < 5 < 5
oz/10
3
cft < 0.005 < 0.005 < 0.005
Engine oil consumption (maximum) g/h 58 58 58
oz/h 2.05 2.05 2.05
Compressed air temperature at outlet
valves
standard °C 90 90 90
°F 194 194 194
with
aftercooler
°C 30 30
°F 86 86
Sound pressure level (Lp), measured
according to ISO 2151/EPA under free
field conditions at 7 m distance
ISO 2151 dB(A) 71 71 71
EPA dB(A) 76 76 76
Sound power level (Lw) complies with
2000/14/EC
ISO 2151 dB(A) 99 99 99
Sound power level (Lw) complies with
84/533/EEC and 85/406/EEC limits
EPA dB(A) 104 104 104
