Unit
1)
Air required for engine and compressor cooling, for combustion and for
compression.
Unit dimensions
Designation
XA(S) 137 DD - XA(S) 300 DD7
XA(S) 137 DDG - XA(S) 300 DD7G
XAHS 107 DD - XAHS 250 DD7
Capacity of compressor oil
system
l13
US gal 3.43
Net capacity of air receiver l 35
US gal 9.25
Capacity of fuel tank l 130
US gal 34
Air volume at inlet grating
(approx.)
1)
m
3
/s 2.5
cfm 88
with brakes towbar
fixed adjustable
Length mm 3768 4278
in 148.3 168.4
Width mm 1676 1676
in 66 66
Height mm 1479 1479
in 58.2 58.2
Weight (ready-to-operate) kg 1500 1450
lb 3306.9 3196.7
