Unit
1)
Air required for engine and compressor element cooling, for combustion and for
compression.
Electric refuel pump
*)
Fuel temperature max 40 °C (104 °F)
Remote control
*)
Obstacles and position of user in relation to receiver (at the rear of the unit) will
reduce the range.
Designation All units
Capacity of compressor oil
system
l82
US gal 21.66
Net capacity of air receiver l 143
US gal 37.78
Capacity of fuel tank (standard) l 975
US gal 257.6
Capacity of fuel tanks
- with skid or support mounted
- with option large fuel tanks
l1550
US gal 409.5
Air volume at inlet grating
(approx.)
1)
m
3
/s 13.9
cu.ft/s 491
Designation All units
Flow rate
*)
l/m 50
US gal/m 13
Self priming
*)
from dry up to m 2.4
ft 7.8
Designation All units
Range
*)
m 200
ft 656
