Atlas Copco XRXS 567 Cd User Manual

- 94 -
Compressor dimensions
Designation All units
Dimensions (overall) L x W x H
Wagon towbar raised m 5.40 x 2.25 x 2.51
inch 233.86 x 88.58 x 101.46
Tandem EU m 6.80 x 2.53 x 3.04
inch 267.71 x 99.61 x 119.69
Support mounted m 4.56 x 2.25 x 2.27
inch 179.53 x 88.58 x 89.37
Skid m 4.56 x 2.25 x 2.44
inch 179.53 x 88.58 x 96.06
Designation All units
Weight (dry)
Wagon kg 7200
lb 15875
Tandem EU kg 8605
lb 18971
Support mounted (option large
fuel tank)
kg 6555 (6685)
lb 14450 (14740)
Skid (option large fuel tank) kg 6775 (6095)
lb 14940 (15225)
Weight (wet, incl. fuel)
Wagon kg 8200
lb 18080
Tandem EU kg 10100
lb 22267
Support mounted (option large
fuel tank)
kg 7555 (8180)
lb 16655 (18035)
Skid (option large fuel tank) kg 7775 (8400)
lb 17140 (18520)
