Text on figure
(1) Menu
(2) Regulation
• Move the cursor to the Outputs icon (see above, section Menu icon), using the Scroll keys.
• Push the Enter key.
Depending on the installed optional equipment less or more icons may appear.
• The outputs are categorized under a number of representative icons. Push the Enter key to show the
actual outputs.
• •
General
• Load/Unload
• Automatic operation
• General warning
• General shutdown
•
Drain(s)
• Condensate drain IC
• Condensate drain AC
• Condensate drain AC2 (AC2 = additional aftercooler for Full-Feature compressors with
energy recovery)
• Condensate drain RC in (RC = Regeneration cooler)
• Condensate drain RC out (RC = Regeneration cooler)
• Condensate drain MD (MD = MD Dryer )
•
Main Motor
• Line contactor
• Star contactor
• Delta contactor
Instruction book
156 2920 1815 04
