• The screen shows a number of icons. Each icon indicates a menu item. The status bar shows the name
of the menu that corresponds with the selected icon.
• Use the Scroll keys to select an icon.
• Press the Enter key to activate the menu or press the Escape key to return to the Main screen.
6.7 Service menu
Control panel
Control panel
(1) Enter key
(2) Escape key
(3) Scroll keys
Menu icon, Service
