Atlas Copco ZR 110 User Manual

380 V - 50 Hz IEC
Compressors designed for a maximum ambient temperature of 40 °C (104 °F) with IE2 motors
Type Cables (H07V2-K) IEC 60364-5-52:
E & 4
mm
2
Fuses gL/gG
(A)
Maximum cable
length
(m)
ZR/ZT 110 2 x (3x 120 + 70) 2X (3X 250) 247
ZR/ZT 132 2 x (3x 120 + 70) 2X (3X 250) 247
ZR/ZT 145 4 x (3x 95 + 50) 2X (3X 315) 179
ZR/ZT 160 4 x (3x 120 + 70) 2X (3X 400) 175
ZR/ZT 200 4 x (3x 120 + 70) 2X (3X 400) 175
ZR/ZT 250 4 x (3x 150 + 95) 2X (3X 500) 179
ZR/ZT 275 4 x (3x 150 + 95) 2X (3X 500) 179
Compressors designed for a maximum ambient temperature of 40 °C (104 °F) with IE3 motors
Type FLA MCA Proposed cable
(mm²)
Maximum
cable
length (m)
Proposed
fuses (A)
(gL/gG)
Maximum
fuse (A)
(gL/gG)
Icc
ZT/ZR 110 239 263 4 X (3 X35+16) 106 2 x(3 X 200) 315 50 kA
ZT/ZR 132 285 314 4 X (3 X70+35) 177 2 x(3 X 250) 315 50 kA
ZT/ZR 145 308 339 2 X (3 X120+70) 245 2 x(3 X 250) 400 50 kA
ZT/ZR 160 371 408 4 X (3 X95+50) 177 2 x(3 X 315) 400 50 kA
ZT/ZR 200 451 496 4 X (3 X 95+50) 177 2 x(3 X 315) 400 50 kA
ZT/ZR 250 566 623 4 X (3 X 120+70) 176 2 x(3 X 400) 500 50 kA
ZT/ZR 275 (7.5
bar)
593 652 4 X (3 X 120+70) 176 2 x(3 X 400) 800 50 kA
ZT/ZR 275 (8.6
and 10 bar)
703 773 4 X (3 X 150+95) 179 2 x(3 X 500) 500 50 kA
FLA and MCA based on an air-cooled full option compressor.
Icc only achieved with recommended fuses.
Compressors designed for a maximum ambient temperature of 50 °C (122 °F) with IE2 motors
Type Cables (H07V2-K) IEC 60364-5-52:
E & 4
mm
2
Fuses gL/gG
(A)
Maximum cable length
(m)
ZR/ZT 110 2 x (3x 150 + 95) 2X (3X 250) 319
ZR/ZT 132 2 x (3x 150 + 95) 2X (3X 250) 319
ZR/ZT 145 4 x (3x 95 + 50) 2X (3X 315) 179
ZR/ZT 160 4 x (3x 150 + 95) 2X (3X 400) 175
ZR/ZT 200 4 x (3x 150 + 95) 2X (3X 400) 175
ZR/ZT 250 4 x (3x 185 + 95) 2X (3X 500) 179
Instruction book
214 2920 1815 04
