Compressors designed for a maximum ambient temperature of 122 °F (50 °C) for IE2 motors
Type
Cables (90° cable) CEC
C22.1
Fuses RK5
(A)
Fuses LPJ
(A)
Maximum cable
length
(m)
ZR/ZT 110
2 x (3x AWG 0000 + AWG
4) 2X (3X 150) 2X (3X 600) 190
ZR/ZT 145
2 x (3x MCM 350 + AWG
3) 2X (3X 200) 2X (3X 600) 265
ZR/ZT 160
2 x (3x MCM 350 + AWG
3) 2X (3X 200) 2X (3X 600) 265
ZR/ZT 200
4 x (3x AWG 0000 + AWG
2) 2X (3X 250) 2X (3X 600) 167
ZR/ZT 250
4 x (3x MCM 300 + AWG
0) 2X (3X 300) 2X (3X 600) 259
Compressors designed for a maximum ambient temperature of 122 °F (50 °C) with IE3 motors or
with oversized motors
Type FLA MCA Proposed cable
(mm²)
Maximum
cable
length (m)
Proposed
fuses (A)
(LPJ)
Maximum
fuse (A)
(LPJ)
SCCR
ZT/ZR 110 203 224 4 X (3 X3AWG
+8AWG)
128 2 x(3 X 150) 600 65 kA
ZT/ZR 145 203 224 4 X (3 X3AWG
+8AWG)
128 2 x(3 X 150) 600 65 kA
ZT/ZR 160 265 291 2 X (3 X250CM
+2AWG)
277 2 x(3 X 200) 600 65 kA
ZT/ZR 200 303 334 2 X (3 X 300MCM
+2AWG)
259 2 x(3 X 225) 600 65 kA
ZT/ZR 250 351 386 4 X (3 X 00+4AWG) 151 2 x(3 X 300) 600 65 kA
FLA and MCA based on an air-cooled full option compressor.
SCCR only achieved with recommended fuses.
Compressors without starter CSA/UL
Compressors designed for a maximum ambient temperature of 104 °F (40 °C)
Type
Cables (90° cable) CEC
C22.1
Fuses RK5
(A)
Fuses LPJ
(A)
Maximum cable
length
(m)
ZR/ZT 110 3x AWG 4 + AWG8 2X (3X 60) 2X (3X 175) 156
ZR/ZT 145 3x AWG 4 + AWG8 2X (3X 60) 2X (3X 175) 156
ZR/ZT 160 3x AWG 4 + AWG8 2X (3X 60) 2X (3X 175) 156
ZR/ZT 200 3x AWG 4 + AWG8 2X (3X 60) 2X (3X 175) 156
ZR/ZT 250 3x AWG 4 + AWG8 2X (3X 60) 2X (3X 175) 156
ZR/ZT 275 3x AWG 4 + AWG8 2X (3X 60) 2X (3X 175) 156
Instruction book
2920 1815 04 225
