Flow diagram of ZT 110 up to ZT 275 compressors and ZT 132 VSD up to ZT 315 VSD compressors
Reference Name
AF Air filter
AO Air outlet
AS Silencer
BV By-pass valve
Ca1 Pre-aftercooler
Ca Aftercooler
Instruction book
