Minimum
setting
Factory
setting
Maximum
setting
Load delay time (not star-delta) sec 20 20 30
Number of motor starts (low-voltage motor) starts/hr 0 3 5
Number of motor starts (high-voltage
motor)
starts/day 0 3 Consult motor
manufacturer
Required stop period sec 5 5 60
Power recovery time sec 1 3 See
Elektronikon
regulator
Minimum stop time sec 20 20 99
Unloading pressure bar(e) 4.1 7.0 7.5
Unloading pressure psig 59.5 101.5 108.8
Unloading pressure bar(e) 4.1 9.0 10.0
Unloading pressure psig 59.5 130.5 145
Unloading pressure bar(e) 4.1 7.0 8.6
Unloading pressure psig 59.5 101.5 124.7
Unloading pressure bar(e) 4.1 9.0 10.4
Unloading pressure psig 59.5 130.5 150.8
Loading pressure bar(e) 4.0 6.0 7.4
Loading pressure psig 58 87 107.3
Loading pressure bar(e) 4.0 8.0 9.9
Loading pressure psig 58 116 143.6
Loading pressure bar(e) 4.0 6.0 8.5
Loading pressure psig 58 87 123.2
Loading pressure bar(e) 4.0 8.0 10.3
Loading pressure psig 58 116 149.4
Protection settings
Minimum
setting
Factory
setting
Maximum
setting
Compressor element 1 outlet temperature
(shut-down warning level)
˚C 100 210 219
Compressor element 1 outlet temperature
(shut-down warning level)
˚F 212 410 426
Compressor element 1 outlet temperature
(shut-down level)
˚C 100 220 220
Compressor element 1 outlet temperature
(shut-down level)
˚F 212 428 428
Compressor element 2 outlet temperature
(shut-down warning level)
˚C 100 210 219
Compressor element 2 outlet temperature
(shut-down warning level)
˚F 212 410 426
Instruction book
2920 1815 04 71
