Steps Of Installation 11
BP12000X
6. Open the parts bag and check the parts according to parts bag list (See Fig. 11).
Fig. 11
D. Position Power Side Columns
Lay down two columns on the installation site parallel, position the power side
column according to the actual installation site. Usually, it is suggested to install
power side column on the right side. Install the top plates (See Fig.12).
Offside column
Power side column
Car-in direction
Assemble top
plate using
M12*30 hex
bolt with nut
and washer.
Fig. 12
