Atlas BP12000X User Manual

Steps Of Installation 12
BP12000X
E. Position Columns, Install Anchor Bolts, Check The
Columns Plumbness With Level Bar, And Adjusting
With The Shims If The Columns Are Not Vertical, Don’t
Tighten The Anchor Bolts At This Time (See Fig. 13)
Note: Set the width to 145 3/8” or 150 ¾”
Adjust the
columns to
vertical with
the shims
118 1/8”
or
123 1/2”
54/54A
Check the columns
plumb (front and
side) with level bar
145 3/8” or 150 3/4”
Fig. 13
