Steps Of Installation 13
BP12000X
F. Fix Anchor Bolts
1. Prepare anchor bolts (See Fig. 14).
2. Use a rotary hammer drill and ¾” masonry bit. Drill all the anchor holes and install
the anchor bolts. Tighten the anchor bolts between 60 and 86 foot pounds.
Fig. 15
G. Install Safety Locks (See Fig. 16 & 17)
Power side safety device Fig. 16
Fig. 14
Lock washer
Washer
Nut
