ATtiny10/11/12
25
cause an interrupt request even if INT0 is configured as an output. The corresponding interrupt of External Interrupt
Request 0 is executed from program memory address $001. See also “External Interrupts.”
•
Bit 5 - PCIE: Pin Change Interrupt Enable
When the PCIE bit is set (one) and the I-bit in the Status Register (SREG) is set (one), the interrupt on pin change is
enabled. Any change on any input or I/O pin will cause an interrupt. The corresponding interrupt of Pin Change Interrupt
Request is executed from program memory address $002. See also “Pin Change Interrupt.”
•
Bits 4..0 - Res: Reserved bits
These bits are reserved bits in the ATtiny10/11/12 and always read as zero.
General Interrupt Flag Register – GIFR
•
Bit 7 - Res: Reserved Bit
This bit is a reserved bit in the ATtiny10/11/12 and always reads as zero.
•
Bit 6 - INTF0: External Interrupt Flag0
When an event on the INT0 pin triggers an interrupt request, INTF0 becomes set (one). If the I-bit in SREG and the INT0 bit
in GIMSK are set (one), the MCU will jump to the interrupt vector at address $001. The flag is cleared when the interrupt
routine is executed. Alternatively, the flag can be cleared by writing a logical one to it. The flag is always cleared when INT0
is configured as level interrupt.
•
Bit 5 - PCIF: Pin Change Interrupt Flag
When an event on any input or I/O pin triggers an interrupt request, PCIF becomes set (one). If the I-bit in SREG and the
PCIE bit in GIMSK are set (one), the MCU will jump to the interrupt vector at address $002. The flag is cleared when the
interrupt routine is executed. Alternatively, the flag can be cleared by writing a logical one to it.
•
Bits 4..0 - Res: Reserved bits
These bits are reserved bits in the ATtiny10/11/12 and always read as zero.
Timer/Counter Interrupt Mask Register – TIMSK
•
Bit 7..2 - Res: Reserved bits
These bits are reserved bits in the ATtiny10/11/12 and always read as zero.
•
Bit 1 - TOIE0: Timer/Counter0 Overflow Interrupt Enable
When the TOIE0 bit is set (one) and the I-bit in the Status Register is set (one), the Timer/Counter0 Overflow interrupt is
enabled. The corresponding interrupt (at vector $003) is executed if an overflow in Timer/Counter0 occurs, i.e., when the
Overflow Flag (Timer0) is set (one) in the Timer/Counter Interrupt Flag Register – TIFR.
•
Bit 0 - Res: Reserved bit
This bit is a reserved bit in the ATtiny10/11/12 and always reads as zero.
Timer/Counter Interrupt Flag Register – TIFR
•
Bits 7..2 - Res: Reserved bits
These bits are reserved bits in the ATtiny10/11/12 and always read as zero.
Bit 7 6 5 4 3 2 1 0
$3A - INTF0 PCIF - - - - - GIFR
Read/Write R R/W R/W R R R R R
Initial value 0 0 0 0 0 0 0 0
Bit 7 6 5 4 3 2 1 0
$39 ---- - -TOIE0-TIMSK
Read/Write R R R R R R R/W R
Initial value 0 0 0 0 0 0 0 0
Bit 7 6 5 4 3 2 1 0
$38 -- ----TOV0-TIFR
Read/Write R R R R R R R/W R
Initial value 0 0 0 0 0 0 0 0
