• Bit 2 – N: Negative Flag
The Negative Flag N indicates a negative result after the different arithmetic and logic
operations. See the Instruction Set description for detailed information.
• Bit 1 – Z: Zero Flag
The Zero Flag Z indicates a zero result after the different arithmetic and logic opera-
tions. See the Instruction Set description for detailed information.
• Bit 0 – C: Carry Flag
The Carry Flag C indicates a carry in an arithmetic or logic operation. See the Instruction
Set description for detailed information.
Reset and Interrupt
Handling
The ATtiny15L provides eight interrupt sources. These interrupts and the separate
Reset Vector each have a separate Program Vector in the Program memory space. All
the interrupts are assigned individual enable bits that must be set (one) together with the
I-bit in the Status Register in order to enable the interrupt.
The lowest addresses in the Program memory space are automatically defined as the
Reset and Interrupt Vectors. The complete list of vectors is shown in Table 3. The list
also determines the priority levels of the different interrupts. The lower the address the
higher is the priority level. RESET has the highest priority, and next is INT0 (the External
Interrupt Request 0), etc.
Table 3. Reset and Interrupt Vectors
Vector No. Program Address Source Interrupt Definition
1 $000 RESET External Reset, Power-on Reset,
Brown-out Reset, and Watchdog
Reset
2 $001 INT0 External Interrupt Request 0
3 $002 I/O Pins Pin Change Interrupt
4 $003 TIMER1, COMPA Timer/Counter1 Compare Match A
5 $004 TIMER1, OVF Timer/Counter1 Overflow
6 $005 TIMER0, OVF Timer/Counter0 Overflow
7 $006 EE_RDY EEPROM Ready
8 $007 ANA_COMP Analog Comparator
9 $008 ADC ADC Conversion Complete
