Hot Water on Demand
Step 1
Fit isolating tap on
cold water supply
Step 2
Having already entered the
power cable, connect to the
terminal block.
Step 7
NL
Blue Wave 402 - Assembly Steps
FREEPHONE 0800 101 201 / sales@atmor.co.nz / www.atmor.co.nz
Position heater at
eye level or higher.
Fix to the wall 2 top
and 1 bottom screw
Step 6
Step 4
Assemble and fit the sliding
shower bar to the wall including
the shower hose and rose
Step 3
Turn on the water to fill
the heating chamber and
check for leaks
Connect cold water supply
inlet hose
Step 5
Attach the front cover, round
the knobs to match the correct
pivot and secure by screw
top and bottom.
For further information on installation and operation
please refer to leaflet enclosed with the heater.
