Atmos C 361 - 3 Assembly; Operating Elements

7
3.0 Assembly
● Alwaysplacethedeviceonarmandlevelsurface.
Fig. 1.
Fig. 2.
Fig. 3.
3.1 Operating elements
 On/o󰀨switchwithpilotlamp
 Vacuum gauge
 Vacuum regulator
Vacuum connection: Direct-Docking-System
 The vacuum connection between the pump and the se-
cretion canister is created automatically as soon as the DDS
canister is positioned correctly!
  
