1-7
TABLE 1-1. SPECIFICATION
MARS 2 MARS 4 MARS 6
Generation
Lens of system
Magnification 2.5X 4X 6X
FOV 14 deg. 9 deg. 6 deg.
Range of focus 5 m to ∞ 10 m to ∞ 25 m to ∞
Eye Relief 45mm
Exit pupil 7mm
Diopter adjustment
Windage & elevation 120MOA 120MOA 80MOA
Adjustment step size 3/8MOA 1/4MOA 1/6MOA
Power supply one 3V (CR123A) or 1.5V (AA)
Battery Life 55 hours (3V)/ 40 hours(1.5V)
Operating
Temperature
Storage
Temperature
Waterproof 1m for 30 min
Reticle Red on Green
Dimensions 215x90x85mm 235x90x95mm 295x95x100mm
Weight 1,1 kg 1,3 kg 1,55 kg
The Mars is an effective night vision system designed for night
ope-rations but does have following limitations:
to operate. Night light is reduced by such factors as passing
cloud cover and objects that produce shadows.
snow, smoke.
snow-covered territory, sandy deserts, large bodies of water
