2-5

2.1.3. LONG RAIL ADAPTER (OPTIONAL)

Long Rail Adapter (LRA) is a quick detachable, multiple eye relief

mounting base that attaches to weaver t ype rail and flat-top recei-

vers designed to give flexibility in positioning your Mars upon a

firearm with a Picatinny or Weaver rail.

Instal the Long Rail Adapter as follows:

1. Loosen the fixing nuts of LRA.

2. Install the LRA onto the weapon mounting rail.

3. Tighten the fixing nuts of LRA tightly.

4. Instal your Mars on the LRA as describe in item 2.1.1

FIGURE 2-5. MARS ON THE LONG RAIL ADAPTER

FIXING NUTS

LONG RAIL ADAPTER
