2-6
2.2. OPERATING PROCEDURES
2.2.1. GENERAL
This section contains instructions for placing the Mars in opera-
tion. The function of controls is explained.
CAUTION
The Mars is a precision electro-optical instrument and must be
handled carefully at all times.
2.2.2. CONTROLS
FIGURE2-5. MARS CONTROLS
REMOTE CONTROL
CONNECTOR
CONNECTOR CAP
OPERATION
SWITCH
DIOPTER ADJUSTMENT RING
RETICLE
BRIGHTNESS
ADJUSTMENT
DUST CAPS
LIGHT SENSOR
