1.2.4. SPECIFICATIONS

The following tables provide information pertaining to the opera-

tional, electrical, mechanical, optical and environmental character-

istics for the sights.

TABLE 1-3. SPECIFICATIONS

THOR-2X THOR-3X

Sensor (microbolometer) 320x240

Type Uncooled 30hz

Image Size (output resolution) NTSC:640x48030hz

Video output NTSC

Display OLED 852x600

ThermalSensitivity,mK 50

Spectral Response, µm 7-14

Focal length of the lens 50 75

Field of View (H x V), deg 12x9 8x6

Angular resolution, mrad 0.6 0.4

Diopter ± 5

Eye Relief, mm 45

Magnification 2x(digital4x) 3x (digital 6x)

Digital Zoom 2

Focus Manual

Focusing range, m 3 to infinity 5 to infinity

Diameter of exit pupil, mm 10

Distance of the human detection, m 915 1350

Distance of the human recognition, m 450 675

Reticle Crosshair, 2 colors

WindageandElevationAdjustment ± 2° ± 1°

StepofWindageandElevationAdjustment 3/4MOA 1/2 MOA

Brightness adjustment Manual

Sharpness adjustment Automatic

Polaritycontrol(onlyinBlackandWhite

mode)

Whitehot/Blackhot

Start up time, seconds <3

Storage temperature, °C -50 to +90

Operating temperature, °C -20 to +60
