1.2.5. MECHANICAL FUNCTION

The mechanical adjustments of the ThOR sights allow for physi-

cal differences between individual operators using the system. The

scope functions include the switchboard, refresh button, universal

connector, eyepiece diopter adjustment ring, focusing ring, battery

compartment cover, mounting rail. The mechanical controls are

identified in Figure 1-5.

FIGURE 1-5. THOR MECHANICAL CONTROLS

DIOPTER ADJUSTMENT RING

UNIVERSALCONNECTORWITHCAP

FOCUSING RING

SWITCHBOARD

BATTERYCOMPARTMENT

COVERWITHSCREWS

QUICKRELEASEMOUNT

PICATINNYRAILS

WINDAGEADJUSTMENT

RETICLE COLOR/BRIGHTNESS

ADJUSTMENT

RUBBEREYECUP

ELEVATION ADJUSTMENT

LENS CAP
