3-2

3.1. GENERAL INFORMATION

3.1.1. GENERAL

This section contains instructions for operation of ThOR. The func-

tion of controls and indicators is explained.

CAUTION

The

ThOR

scope is a precision electron-optical instrument and

must be handled carefully at all times.

3.1.2. CONTROLS AND INDICATION

The ThOR scope is designed to adjust for different users and cor-

rects for most differences. The controls for the scope are shown or

described in Figure 3-1 and Tables 3-1.

FIGURE 3-1. CONTROLS
