TABLE 3-1. CONTROLS AND INDICATION

ITEMS

CONTROLS AND

INDICATORS

FUNCTIONS

1 ON/OFF Button Controls scope power.

To turn the unit on and

off press the button

2 BRIGHTNESS

Buttons

Adjustment of

the output image brightness.

3 POLARITY

Button

Switch from hot-white/cold-black into hot-

black/cold-white mode (only in Black and

Whitemode).

4 ZOOM Button Digital magnification On.

5 TOUCH UP

Button

Maintains an optimum thermal image.

6 Diopter Adjust-

ment

Focuses eyepiece lens without the need for

glasses. Adjusts for sharper image of intensi-

fier screen.

7 Reticle color/

brightness ad-

justment knob

Adjusts color (red or green) and brightness

(5 steps) of reticle

8 Objective Lens

Focus

Focuses objective lens. Adjusts for sharpest

image of viewed object.
