ATN Zebra 12 User Manual

OPERATOR’S AND SAFETY HANDBOOK
1NO0060EN-00
Zebra 12 – Zebra 16
12
1.1.2. Zebra 16 – Zebra 16 Stab
(1) (2)
(3)(3)
(4)
(5)
(6) (7)
(9)
(10)
(11)
(12)
(15) (14)
(16)
(13)
(8)
1. Oscillating front axle – Steering
2. Rear axle
3. Outriggers (Z16 Stab only)
4. Fuel tank (Diesel)
5. Combustion engine compartment
6. Hydraulic tank
7. Ground control station
8. Turret
9. Arm 1
10. Arm 2
11. Telescope
12. Arm 3
13. Rotator
14. Work platform
15. Work platform control station
16. Manual storage box
