OPERATOR’S AND SAFETY HANDBOOK
1NO0060EN-00
Zebra 12 – Zebra 16
27
2.7 OPERATING LIMITS
Model
Zebra 12
Zebra 16
Zebra 16
STAB
Max floor height
10.20 m
14.40 m
14.80 m
Maximum working height
12.20 m
16.40 m
16.80 m
Maximum number of people authorised on the
work platform
2
Maximum load on the platform (distributed)
230kg
Maximum wind speed
12.5m/s (45km/h)
Maximum manual force
400 Newton
Maximum tilt on wheels
Transversal
4 degrees
5 degrees
Longitudinal
4 degrees
5 degrees
Maximum tilt on outriggers
Transversal
-
1 degree
Longitudinal
-
1 degree
Max slope (see Note)
40 %
45%
43%
Operating temperature
-20 … +60°C
- NOTE-
Do not run the diesel engine for more than 10 minutes on a tilt or slope of over 35%.
2.8 TOWING, LIFTING, TRANSPORT
• Do not tow, lift or transport the machine with people or material on the work platform.
• Lower the platform completely before towing, lifting, or transporting the machine.
• The machine must only be towed or lifted in the event of an emergency, a malfunction, a fault
or for loading/unloading. See 7.3 – Emergency towing.
• Lifting operations must be done considering recommendations given in paragraph 4.8.1.
• Check the capacity of the equipment used to tow, lift, or transport the machine.
2.9 MAINTENANCE
• To guarantee the machine's safety, a maintenance and inspection programme taking into
account the information provided in this manual must be established by a qualified person.
• Before performing any maintenance or repair operations, cut the power to the control stations.
• Never work under the work platform or on the elevating structure without it being supported
and immobilised by appropriate slinging.
• Disconnect the battery when working on the machine's electrical circuit or during welding
operations.
• Do not smoke, approach bare flames, or create sparks near the battery.
• Do not place any metal tools or objects on the battery terminals.
