ATN Zebra 12 User Manual

OPERATOR’S AND SAFETY HANDBOOK
1NO0060EN-00
Zebra 12 – Zebra 16
11
1.1. DESCRIPTION
1.1.1 Zebra 12
( 7 )
( 8 )
( 9 )
( 10 )
( 11 )
( 12 )
( 14 )
( 15 )
( 16 )
( 1 )
( 2 )
( 3 )
( 4 )
( 5 )
( 6 )
1. Oscillating front axle – Steering
2. Rear axle
3. Fuel tank (Diesel)
4. Combustion engine compartment
5. Hydraulic tank
6. Ground control station
7. Turret
8. Arm 1
9. Arm 2
10. Telescope
11. Arm 3
12. Rotator
13. Work platform
14. Work platform control station
15. Manual storage box

ATN Zebra 12 Specifications

General

Brand	ATN
Model	Zebra 12
Category	Boom Lifts
Language	English
