7.1 EMERGENCY CONTROLS
The emergency controls must only be used by personnel with detailed knowledge of the
machine's operating characteristics and the ground control functions.
Should the platform get jammed or stuck in an overhead structure or equipment, stop operating
the machine immediately. Use other equipment to rescue the platform's occupants. Stabilise the
machine before you try to release it. Make sure you do not control any movements that might
lead to the machine tipping over.
7.1.1. EMERGENCY STOP
Each control station is fitted with an emergency stop switch that stops the movements of the
machine and cuts the combustion engine when pushed in.
7.1.2. GROUND CONTROL STATION
The priority control station on the ground is used to raise or lower the platform in the event of
an emergency when the operator on the work platform is unable to operate the machine.
1- Set the control station selector to "ground control station ".
2- Start the combustion engine.
3- Check that there are no overhead obstacles that might interfere with the machine’s
movements
4- Activate the appropriate controls to raise or lower the platform
7.1.3. AUXILIARY HYDRAULIC GROUP
In the event of a breakdown on the combustion engine, an auxiliary group is used to power
the machine's hydraulic circuit to return the platform to its low position. The hydraulic group is
powered by the combustion engine's start-up battery. It may be used from the ground control
station or from the work platform's control station. The auxiliary hydraulic group may only be
used when the combustion engine is stopped. The outriggers cannot be controlled by the
auxiliary hydraulic group (Zebra 16 Stab).
• From the ground control station
1- Tilt downwards and hold the Start / Auxiliary Group button.
2- Use the controls to lower the platform.
• From the work platform control station
1- Press on the enable pedal.
2- Keep the Start / Auxiliary Group button tilted downwards.
3- Use the controls to lower the platform.
