11
Installation du capot de guidage
d'air pour huit modèles
Atomstack A5
M50 Pro
AtomStack P9 M40
Atomstack X7 Pro
AtomStack P9
M50
AtomStack A10 PRO
Atomstack A5 M50
Atomstack S10 Pro
Atomstack X7
1. Retirez la vis de réglage
du côté droit du laser et
retirez le verre filtrant
actuel ou le bouclier
acrylique .
2. Retirer le guide
d'air actuel.
3. Trouvez NO.1 et NO.1-2 parmi
les accessoires et installez-les en
même temps comme indiqué.
4. Fixez le guide
d'air ainsi que le
verre filtrant.
5. Insérez le tuyau.
