www.leyard.com | www.planar.com Page 2/6
© Leyard & Planar 2019
SPECIFICATION DATA 1 DESIGN 1
Product Family Clarity Matrix G3
Product Model LX46U-L-ERO
Video Controller Model VC4H-BP+
Total Number of Panels/Cabinets (Displays) 4
Total Number of Display Mounts 4
Video Wall Conguration 2W x 2H
Display Orientation Landscape
Display Brightness (nits) 500
Redundant Signal Congured N/A
Redundant Power Congured No
Fiber Option Congured No
MultiTouch Option Congured Yes
ERO™ Option Congured Yes
Video Wall Dimensions
Video Wall (width/height/depth) (ft) 7.15 W x 4.23 H x 0.39 D
Active Display (width/height/depth) (ft) 6.72 W x 3.79 H x 0.31 D
Active Display Area (ft²) 25.49 ft²
Active Display Diagonal(in) 92.58
Total Resolution (W x H) 3840 x 2160
Distance From Controllers to Video Wall (ft) 200.0 ft
Distance From Remote Power Supply to Video Wall (ft) 200.0 ft
Video Wall Weight
Total Wall Weight (Displays) (lbs) 188
Total Weight (Mounts) (lbs) 28.88
Total Weight (Options) (lbs) 27.52
Power
Power Voltage Range (VAC) 120
Max Product Input Current (Amps AC) 15
Max Displays Per Power Chain
120VAC@15A 8
240VAC@16A 8
Remote Power Supplies Yes
External Components - Video Wall
Video Receiver Type CATx
Video Receiver Quantity N/A
