6 – ARCHITECTS & ENGINEERING SPECIFICATION
The Dante™/AES67 2-gang wall plate interface unit shall provide a stereo Bluetooth® 3.0 compatible audio receiver in a
Décora form factor. The Bluetooth® receiver shall be activated for pairing and connection by a single button on the wall
plate. The Bluetooth® receiver shall also feature remote customization via a software control interface.
The device shall also provide two sets of unbalanced line level input connections: one on a set of RCA connectors, the
other using a stereo 3.5mm TRS connection (each summed to mono). These inputs are selectable for independent or
summed operation via software and introduced to the Dante™/AES67 interface on Dante™/AES67 transmit channels 3
and 4. The internal analog to digital signal conversion shall be performed at 24-bit resolution with a sampling frequency
of 48 kHz.
The Dante™/AES67 Bluetooth interface shall support bidirectional call-bridging capabilities as well as unidirectional media
streaming receiver functionality.
The two received Dante™/AES67 output channels shall also be converted and output on a front panel mounted 3.5mm
stereo TRS connector. The internal digital to analog signal conversion shall be performed at 24-bit resolution with a
sampling frequency of 48 kHz.
The Dante™/AES67 interface unit shall receive power over the Ethernet cable from an IEEE 802.3af PoE compliant network
switch or midspan injector.
The Dante™/AES67 interface shall be compliant with the RoHS, WEEE and REACH directives. The Dante™/AES67 interface
unit shall be Compliant with the EMI/EMC requirements for FCC and CE.
The Dante™/AES67 interface unit shall be the Attero Tech unD6IO-BT.
