unD6IO-BT
User Manual
Attero Tech LLC 2019 Page 4 614-00033 Rev 01_e
1 – Overview
The unD6IO-BT Dante™/AES67 Audio Interface with Bluetooth® is a cost effective multi‐IO wall box. The unD6IO-BT
features stereo Bluetooth® wireless audio input connectivity along with two RCA line level inputs and a 3.5mm TRS line
level input. A 3.5mm TRS line level output on the front is also included.
T
he unD6IO-BT is designed to fit into most dual gang US junction boxes and is PoE enabled, so all connectivity (power,
control and audio data) is provided by a single CAT‐5e/6 cable. The unD6IO-BT’s unique mix of consumer style wired and
wireless connectivity allows easy connection of a wide variety of user devices to a Dante™/AES67 network with no concerns
about ground loops or other audio problems common with consumer devices.
T
he unD6IO-BT includes the following features:
o Simple pairing one button pairing/connect process for standalone operation with LED indication of connection
s
tatus
o Configurable pairing button for use with and without 3rd party control systems
o Customizable Bluetooth® friendly name in applications with co -located unD6IO-BTs
o Compatible with most smartphones, Apple iPads, and Android tablets
o Two RCA and one 3.5mm stereo input
o One 3.5mm stereo output with software volume control
o IEEE802.3af compliant PoE powered to work with any compliant PoE network switch
o RCA inputs and 3.5mm input (each summed to mono) can be selected individually or in combination as an audi
o
f
low via software (see Audio Flow diagram)
o Bluetooth® audio is carried as stereo onto the Dante™/AES67 network
o Bluetooth® call bridging capability for conferencing purposes
A
udinate’s Dante™ Controller or other 3rd party manufacturer's Dante™ routing software can be used to control the
audio routing configuration of the device along with enabling of AES67 streams.
1.1 – What’s in the Box
The device comes supplied with the following:
o (1) unD6IO-BT ( P/N 900-00193)
o *Note: This product is available in different color and control compatibility options. Consult the most
current catalog or pricelist for the latest ordering information.
o (1) 2-gang Decora cover plate cover w/mounting screws
