Extron DTP CrossPoint 108 4K, DTP CrossPoint 86 4K, DTP CrossPoint 84 4K,
DTP CrossPoint 82 4K Matrix Switchers • Specifications
2
Connectors
DTP CrossPoint 108 4K ���������� 6female HDMI type A
4female RJ-45
DTP CrossPoint 86 4K
������������ 6female HDMI type A
2 female RJ-45
DTP CrossPoint 84 4K
������������ 6female HDMI type A
2 female RJ-45
DTP CrossPoint 82 4K
������������ 6female HDMI type A
2 female RJ-45
Matrix video outputs (non scaled)
Number/signal type
DTP CrossPoint 108 4K ���������� 4HDMI digital video (HDCP compliant)
DTP CrossPoint 86 4K ������������ 2 HDMI digital video (HDCP compliant)
DTP CrossPoint 84 4K ������������ 2 HDMI digital video (HDCP compliant)
DTP CrossPoint 82 4K ������������ 0
Connectors
DTP CrossPoint 108 4K ���������� 4 female HDMI
DTP CrossPoint 86 4K ������������ 2female HDMI
DTP CrossPoint 84 4K ������������ 2 female HDMI
DTP CrossPoint 82 4K ������������ 0
Scaled TP outputs
Number/signal type
DTP CrossPoint 108 4K ���������� 4DTP, XTP, or HDBaseT (configurable)
2 buffered HDMI digital video (HDCP compliant)
DTP CrossPoint 86 4K
������������ 4DTP, XTP, or HDBaseT (configurable)
2 buffered HDMI digital video (HDCP compliant)
DTP CrossPoint 84 4K
������������ 2 DTP, XTP, or HDBaseT (configurable)
2 buffered HDMI digital video (HDCP compliant)
DTP CrossPoint 82 4K
������������ 2 DTP, XTP, or HDBaseT (configurable)
2 buffered HDMI digital video (HDCP compliant)
Connectors
DTP CrossPoint 108 4K
���������� 4female RJ-45
2 female HDMI
DTP CrossPoint 86 4K
������������ 4female RJ-45
2 female HDMI
DTP CrossPoint 84 4K
������������ 2female RJ-45
2 female HDMI
DTP CrossPoint 82 4K
������������ 2female RJ-45
2 female HDMI
Video processing
Digital pixel data bit depth
������� 8, 10, or 12 bits per channel;300 MHz pixel clock (HDMI)
Colors ������������������������������������� 1�07 billion (10-bit processing)
Video input
Horizontal frequency ���������������� 15 kHz to 100 kHz
Vertical frequency �������������������� 24 Hz to 75 Hz
Resolution range ��������������������� 640x480 to 1600x1200 and 1920x1200* 480i, 480p, 576i, 576p, 720p, 1080i,
1080p, and 2K through 4K @ 30Hz
*reduced blanking
