Extron DTP CrossPoint 108 4K, DTP CrossPoint 86 4K, DTP CrossPoint 84 4K,
DTP CrossPoint 82 4K Matrix Switchers • Specifications
4
Supported formats — Pass through
HDMI connectors �������������������� LPCM up to 7�1/24-bit/192kHz, Dolby TrueHD, Dolby Digital Plus, Dolby Digital
EX, Dolby Digital 5�1, Dolby Digital 2/0 Surround, Dolby Digital 2/0, DTS-HD
Master Audio, DTS-HD, DTS ES Discrete 6�1, DTS ES Matrix 6�1, DTS Digital
Surround 5�1, DTS 2 Channel
Analog conectors �������������������� Analog stereo audio
DTP connectors ���������������������� De-embedded from HDMI [PCM only] or remote balanced/unbalanced analog
Audio input
Number/signal type
DTP CrossPoint 108 4K ���������� 6 stereo, analog line level, balanced or unbalanced
6stereo, de-embedded from HDMI (PCM only)
4DTP (de-embedded from HDMI [PCM only] and remote balanced/unbalanced
analog), orXTP (embedded digital)
DTP CrossPoint 86 4K
������������ 6 stereo, analog line level, balanced or unbalanced
6stereo, de-embedded from HDMI (PCM only)
2DTP (de-embedded from HDMI [PCM only] and remote balanced/unbalanced
analog), orXTP (embedded digital)
DTP CrossPoint 84 4K
������������ 6 stereo, analog line level, balanced or unbalanced
6 stereo, de-embedded from HDMI (PCM only)
2 DTP (de-embedded from HDMI [PCM only] and remote balanced/unbalanced
analog), or XTP (embedded digital)
DTP CrossPoint 82 4K
������������ 6 stereo, analog line level, balanced or unbalanced
6 stereo, de-embedded from HDMI (PCM only)
2 DTP (de-embedded from HDMI [PCM only] and remote balanced/unbalanced
analog), or XTP (embedded digital)
Connectors
DTP CrossPoint 108 4K
���������� (6) 3�5 mm captive screw connectors, 5-pole for analog line level inputs
6female HDMI type A
4female RJ-45
DTP CrossPoint 86 4K
������������ (6) 3�5 mm captive screw connectors, 5-pole for analog line level inputs
6female HDMI type A
2female RJ-45
DTP CrossPoint 84 4K
������������ (6) 3�5 mm captive screw connectors, 5-pole for analog line level inputs
6female HDMI type A
2 female RJ-45
DTP CrossPoint 82 4K
������������ (6) 3�5 mm captive screw connectors, 5-pole for analog line level inputs
6female HDMI type A
2 female RJ-45
Analog audio
Nominal level
��������������������������� +4 dBu, -10 dBV adjustable via input gain
Maximum level ������������������������� +21 dBu balanced, +15 dBu unbalanced
Input gain adjustment �������������� -18 dB to +24 dB, 0�1 dB steps, adjustable per input
NOTE: Unbalanced analog inputs at a DTP Tx input have +12 dB of gain applied to bring the signal to a nominal
level for balanced operation�
NOTE: 0 dBu = 0�775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Mic/line input
Number/signal type ������������������������ 4 mono, mic/line, balanced/unbalanced (with phantom power)
Connectors ������������������������������������ (4) 3�5 mm captive screw connectors, 3-pole
Impedance ������������������������������������� 10k ohms unbalanced, 20k ohms balanced
Nominal level ���������������������������������� -60 dBV, +4 dBu, -10 dBV, adjustable via input gain
Maximum level ������������������������������� >+21 dBu at rated THD+N when mic gain is set to 0 dB
Equivalent input noise �������������������� <-120 dBV (1�0µVrms) at +40 dB input gain
CMRR �������������������������������������������� >70 dB typical
