Control
®
26C/CT
Professional Series – Background/Foreground Ceiling Speaker
SPECSHEET
Key Features:
• Coaxially mounted 165 mm (6.5 in) woofer with butyl rubber surround and 19 mm (¾ in)
titanium coated diffraction-loaded tweeter
• High power, wide frequency response and low distortion for high sound level capability
• Wide coverage allows fewer speakers, reducing the cost of the installed sound system
without sacrificing performance
• JBL’s exclusive SonicGuardTM overload protection allows higher operational levels and
improved system reliability (26C only)
• Packaged with grille, backcan and tile rails for fast installation and easy dealer stocking
Description:
The Control 26C is a compact ceiling speaker providing premium
performance in background, foreground music sound systems. The
Control 26C is perfectly suited for a wide variety of applications from
casinos and hotels to upscale restaurants and themed locations. High
power handling, wide frequency response and low distortion make
the Control 26C ideal for sound systems requiring a higher fidelity
sound from ceiling loudspeakers. The premium performance capability
ensures excellent sound character, providing pleasant, enveloping sound
throughout the listening area.
The Control 26C’s 16 ohm impedance allows use of multiple speakers
in parallel without having to use a more expensive constant voltage
distributed system. The optional Control 26CT version includes a multitap
transformer for 70V/100V systems.
JBL’s exclusive SonicGuard overload protection is a non-invasive
loudspeaker protection system that is inaudible to the listener, ensuring
reliability while providing full fidelity sound. The computer-optimized
ported enclosure delivers warm, smooth bass response. Low frequency
output can be further augmented with the addition of one of the Control
Contractor subwoofer models.
The 165 mm (6.5 in) woofer features a polyurethane-coated cone
and pure butyl rubber surround for long life, even in high humidity
environments. An aluminum voice coil former provides extra cooling for
greater long-term power handling.
The coaxially mounted 19 mm (¾ in) titanium coated tweeter provides
crisp, clear highs. Diffraction-loading of the tweeter provides wide, even
coverage of the listening area. The extremely broad 110° coverage
pattern allows for fewer speakers to be used, making for a simpler and
less expensive installation.
Specifications:
System
Freq. Range (-10 dB)
1
75 Hz – 20 kHz
Power Capacity
2
150W Continuous Program Power
75W Continuous Pink Noise
Nominal Sensitivity
3
89 dB SPL, 1W @ 1 m (3.3 ft)
Nominal Coverage Angle
4
110° conical coverage
Directivity Factor (Q) 5.9 averaged 500 Hz to 4 kHz
Directivity Index (DI) 4.6 averaged 500 Hz to 4 kHz
Rated Maximum SPL 107 dB @ 1 m (3.3 ft)
Nominal Impedance (26C) 16 ohms (Min Z: 16.5 Ω @ 290 Hz)
Transformer Taps (26CT) 70V: 60W, 30W, 15W & 7.5W taps
100V: 60W, 30W, & 15W taps
Transducers
Low Frequency 165 mm (6.5 in) polypropelene-coated, 1” coil on
aluminum former
High Frequency 19 mm (¾ in) titanium-coated polyester
Physical
Enclosure Backcan: Formed steel
Baffle/Rim: Medium impact polystyrene, fire rated
UL94V-0
Overload Protection Full-range power limiting to protect network and
transducers (Control 26C only).
Termination Removable locking connector with screw-down
terminals. 2 input terminals and 2 loop-thru output
terminals. Max. wire 12 AWG (2.5 mm
2
)
Safety Agency Rating Suitable for use in air handling spaces per UL1480,
UL2043, NFPA90 & NFPA 70. S7232/UL Listed,
Signaling Speaker. Transformer UL registered per
UL1876. In accordance with IEC60849/EN60849.
Outside Dimensions (H x Dia) 210 x 252 mm (8.3 x 9.9 in)
190 mm (7.5 in) front of ceiling tile to back of
backcan
Cutout Size 220 mm (8.75 in)
Net Weight (each) 3.4 kg (7.5 lb) CT: 4.2 kg (10 lb)
Shipping Weight (pair) 8.1 kg (18.0 lb) CT: 9.7 kg (21 lb)
Included Accessories » C-shaped support backing plate
» 2 tile support rails
(fits both 2 x 4 ft or 600 x 1200 mm tiles)
» Cutout template
» Paint shield
» Removable locking wiring connector
1
Half-space (flush mounted in ceiling)
2
Continuous Pink Noise rating is IEC-shaped pink noise with a 6 dB crest factor for
100 hours continuously. Continuous Program power is a conservative expression
of the system’s ability to handle normal speech and music program material and is
defined as 3 dB above the Continuous Pink Noise Rating.
3
Half-space (in ceiling), average 100 Hz to 10 kHz
4
500 Hz to 4 kHz
JBL continually engages in research related to product improvement. Changes
introduced into existing products without notice are an expression of that philosophy.
Included grille not shown
