TH109PLUS
5
Connect the thermostat wires to the heating system (load) and
to the power supply.
Wiring
2-wire Installation
4-wire Installation
400-109-005-A (Calypso) ENG.fm Page 5 Monday, November 30, 2009 2:36 PM
