Additional Information
Technical specifications
LINO4 LINO10
Max Power 40 Watt 80 Watt
RMS Power 20 Watt 40 Watt
Nominal impedance 8 Ω 20 Ω
Line transformer taps 250 Ω – 70V/20W 125 Ω – 70V/40W
500 Ω – 100V/20W - 70V/10W 250 Ω – 100V/40W - 70V/20W
1k Ω – 100V/10W - 70V/5W 500 Ω – 100V/20W - 70V/10W
2k Ω – 100V/5W - 70V/2.5W 1k Ω – 100V/10W - 70V/5W
Frequency response (± 3 dB) 170 Hz - 15 kHz 170 Hz - 15 kHz
Frequency range (- 10 dB) 120 Hz - 20 kHz 120 Hz - 20 kHz
Sensitivity (1W/1m) 88 dB 90 dB
Sound pressure (Max. W/1m) 101 dB 107 dB
Cross-over network Passive built-in Passive built-in
Drivers 4 x 2” + 1” HF 10 x 2” + 1” HF
Connectors 6-pin Terminal block (5.08 mm) 6-pin Terminal block (5.08 mm)
Mounting bracket Adjustable L-brackets (steel) Adjustable L-brackets (steel)
Construction Alu extrusion + end caps Alu extrusion + end caps
Front finish Fine perforated alu grill Fine perforated alu grill
Ingress protection IP3x IP3x
Operation temperature range -20°C to +50°C -20°C to +50°C
Colour White LINO4/W (RAL9003) LINO10/W (RAL9003)
Black LINO4/B (RAL9005) LINO10/B (RAL9005)
Dimensions (W x H x D) 72 x 414 x 68.3 mm 72 x 796 x 68.3 mm (excl bracket)
Weight 1.81 Kg 3.7 Kg
Packaging Carton box Carton box
Shipping weight & Volume 2.1 Kg - 0.008 Cbm 4.2 Kg - 0.014 Cbm
Accessories included 6-pin terminal block connector 6-pin terminal block connector
Adjustable L-brackets (steel) Adjustable L-brackets (steel)
