100 V Example connection diagram
Multiple loudspeakers can be connected in parallel, on both output connection terminals.
-
-
Matching
Transformer
Matching
Transformer
+
+
-
Matching
Transformer
+
8 Ω Example connection diagram
Only one 8 Ω loudspeaker or two 16 Ω low impedance loudspeakers are allowed to be
connected in parallel, when the amplifier is switched in 8 Ω mode.
-
+
8 Ω
-
+
16 Ω
-
+
16 Ω
To Next Page
