Chapter 6
Additional information
Technical specifications
RMS Output Power PMQ240 @ 100 Volt 4 x 240 Watt
(1 kHz, THD 1%) @ 8 Ω 4 x 240 Watt
PMQ480 @ 100 Volt 4 x 480 Watt
@ 8 Ω 4 x 480 Watt
PMQ600 @ 100 Volt 4 x 600 Watt
@ 8 Ω 4 x 600 Watt
Min load impedance PMQ240 @ 100 Volt 41.7 Ω
@ 8 Ω 8 Ω
PMQ480 @ 100 Volt 20.8 Ω
@ 8 Ω 8 Ω
PMQ600 @ 100 Volt 16.7 Ω
@ 8 Ω 8 Ω
Frequency response 20 Hz - 20 kHz
Signal to Noise Ratio > 95 dB
Total Harmonic Distortion + Noise < 0.05%
Common Mode Rejection 70 dB
Crosstalk > 70 dB
Inputs Type Balanced Line
Connectors Female XLR Input
3-pin Terminal block ~ 3.81 mm
Impedance 10 k Ohm balanced
Sensitivity -30 dB ~ +5 dB
Output Type Loudspeaker Output
Connectors 4-pin Terminal Block ~ 5.08 mm
Controls DSP configuration through front panel
RS-232
Indicators Power
Protect
Peak
-20 dB
Signal
Protection DC-Short Circuit
Over Heating
Over Load
Limiter
Cooling system Temperature controlled fan
