22
Channel name
Bit number
Data value
Description
FLAG_FBX_F5
bit8
-------8
Sadev pump
bit7
------7-
HR-ECU
bit6
-----6--
HR-Fuel pump
bit5
----5---
Starter
bit4
---4----
Radio
bit3
--3-----
HR-Lambda
bit2
-2------
HR-Miscellaneous
bit1
1-------
HR-Injectors
FLAG_FBX_F4
bit8
-------8
MR-ignition coils
bit7
------7-
Sadev-ELV
bit6
-----6--
Drink
bit5
----5---
Switch panel / Aux. data connector
bit4
---4----
Steering wheel
bit3
--3-----
Gear Lever / GCU
bit2
-2------
Diagnosis connector
bit1
1-------
Power steering ECU
FLAG_FBX_F3
bit8
-------8
ECU
bit7
------7-
Front fan
bit6
-----6--
MXG
bit5
----5---
Blackbox / Gateway
bit4
---4----
Differential
bit3
--3-----
+30 Aux. connector
bit2
-2------
DSG
bit1
1-------
ABS ELV
FLAG_FBX_F2
bit8
-------8
Wiper
bit7
------7-
Turn light
bit6
-----6--
Diagnosis connector / +15 aux. connnector
bit5
----5---
Cockpit fan
bit4
---4----
Window
bit3
--3-----
Head lights
bit2
-2------
Transponder
bit1
1-------
+15 signal
FLAG_FBX_F1
bit8
-------8
Wiper pump
bit7
------7-
Brake light
bit6
-----6--
Low beam
bit5
----5---
Day light
bit4
---4----
Low beam
bit3
--3-----
Rear light
bit2
-2------
Rain light left
bit1
1-------
Rain light right
FLAG_FBX_RELAY2
bit8
-------8
bit7
------7-
bit6
-----6--
Turn light L
bit5
----5---
Turn light R
bit4
---4----
Cockpit fan
bit3
--3-----
M relay
bit2
-2------
H relay
