Audi V8 - Page 31

31
SSP217_052
Intake manifold changeover
solenoid valve N261, stage 2
Non-return valve
Vacuum unit,
stage 2
Intake manifold changeover
solenoid valve N156, stage 2
From vacuum reservoir
From vacuum
reservoir
Vacuum unit,
stage 3
Secondary air inlet
valve N112
