9
The central bolt does not have to be
unscrewed for the vibration damper to be
removed.
The marking indicates the ignition TDC of the
5th cylinder.
SSP217_050
Central bolt
Marking
Engine mounting
To enhance driving comfort, hydraulic engine
mounts with electrical activation are used for
the 8-cylinder engines.
They function in the way as described in
SSP 183/16.
The mounts are activated by the engine
control unit according to engine speed and
vehicle speed.
Electrical connection
SSP217_039
