SUB-GRP INSERT/
LINE INPUT 17-24
CONNECTORS
This panel carries the connectors
for the sub-group insert points.
There are 8 sub-groups and each
insert point has a send output and
a return input.
Signal is always present on the
send output. If required the insert
returns could be used as very basic
inputs to the stereo mix bus during
mixdown, from a submixer or
sampler etc.
The insert return jacks can also
be used to provide 8 additional
line inputs to the mix. These are
designated as Line inputs 17-24.
Note that the additional line inputs
are not available if the insert return
is also being used.
Console functions.
