Page -8-

Frequency Response

Mic input to Mix output <+0,-0.3dB 20Hz-20kHz @6-40dB gain.

Line input to Mix output <+0,-0.3dB 20Hz-20kHz @0dB gain.

THD AND NOISE AT +20dB OUTPUT

Mic XLR input to any output <0.005% at 1kHz

Line input to any output <0.005% at 1kHz

Tape input to any output < 0.003% at 1kHz

NOISE

Mic EIN (20-20kHz, 150R source) <-127.5dBu

Bus noise (no inputs routed) <-93dBu

Bus noise (36 inputs routed) <-78dBu

CROSSTALK AND MUTE ATTENUATION AT 1kHz

Short fader Mute >90dB

Long fader Mute >90dB

Mix assign >90dB

Bus assign >90dB

MIC CMRR 70dB (Min gain)

75dB (Max gain)

MAXIMUM INPUT

Mic >+21dBu (min gain)

Line +30dBu (min gain)

insert return >+21dBu

MAXIMUM OUTPUT INTO 2K OHMS

Mix output >+26dBu

Bus output >+26dBu

Aux output >+26dBu

Insert send >+20dBu

Monitor, Studio, F/B outputs >+20dBu

Specications
