Audient evo 16 - Specifications

SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Phantom Power:
INPUT IMPEDANCE:
48v +/-4v @ 10mA/Channel
500k
CMRR:
THD+N @ 0dBu (1kHz):
>80dB @ 1kHz
<0.1%
Maximum Input Level: +16dBu
Input Impedance (Mic): >3kΩ Balanced
Input Impedance (Line):
>10kΩ Balanced
Frequency Response: +/-0.5dB 10Hz to 40kHz
Crosstalk: <-105dBu @ 1kHz <-103 @ 10kHz
THD+N @ 0dBu (1kHz): <0.0015%
SNR: 100dB
Mic EIN: <-127.5dBu
XLR:
1/4” Jack:
Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
TIP (Hot), RING (Cold) & SLEEVE (Shield)
DIGITAL TO ANALOGUE CONVERTER
MICROPHONE PREAMPLIFIER:
Mic Gain Range: 58 dB
Line Gain Range: 58dB with -10dB Pad
D.I:
D.I Gain Range:
MAXIMUM INPUT LEVEL:
SNR:
FREQUENCY RESPONSE:
58dB
+10dBu
100dB
1/4” JACK: TIP (Hot) & SLEEVE (Shield)
+/-0.5dB 10Hz to 20kHz
Maximum Output Level:
Digital Reference Level:
12dBu
0dBFS = +10.5dBu
Digital Reference Level:
Frequency Response:
0dBFS = +12dBu
+/-0.5dB 10Hz to Fs/2
Output Impedance:
Crosstalk:
<50Ω
-125dBu @ 1kHz & 10kHz
Frequency Response:
THD+N @ -1dBFS (1kHz):
+/-0.5dB 10Hz to Fs/2
<0.001%
Crosstalk:
Dynamic Range:
<-110dBu @ 1kHz
112.5dB A-Weighted
THD+N @ -1dBFS (1kHz): <0.001%
Dynamic Range: 121dB A-weighted
1/4” Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)
HEADPHONE OUTPUT:
Output Impedance: <50Ω
Max Output Level: 11.25dBu
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: -108dBu @ 1kHz
THD+N @ -1dBFS (1kHz): <0.001%
Dynamic Range: 118dB A-weighted
Max Level Into 30ohms: +8.5 dBu, 0.00094% THD+N,
1.66Vpk Power: 86mW
Max Level Into 60ohms:
10 dBu, 0.00079% THD+N,
2.55Vpk Power: 104mW
Max Level Into 600ohms:
11.2 dBu, 0.00057%THD+N,
3.83Vpk Power: 24mW
1/4” Jack: TIP (Left), RING (Right) & SLEEVE (Shield)
ANALOGUE TO DIGITAL CONVERTER
