15
Specifications
Turntable specifications
Type 3-speed, fully manual operation
Motor High-torque DC motor
Drive method Direct drive
Speeds 33-1/3 RPM, 45 RPM, 78 RPM
Turntable platter Die-cast aluminum
Starting Torque > 2.2 kgf.cm
Braking System Electronic brake
Wow and flutter < 0.2% WRMS (33 RPM) at 3 kHz
Signal-to-noise ratio > 50 dB
Output level 5.5 mV nominal at 1 kHz, 5 cm/sec
Tonearm specifications
Type Static balanced S-shaped tonearm
with detachable headshell
Effective length 230.5 mm
Overhang 16 mm
Maximum tracking error angle Less than 3°
Stylus pressure adjustment
range
0 to 4 g
Applicable cartridge weight
range
3.5 to 8.5 g
Cartridge and headshell specifications
Cartridge Model AT-XP3
Cartridge Type VM
Recommended load
impedance
47,000 ohms
Output voltage 5.5 mV (1 kHz, 5 cm/sec)
Stylus 0.6 mil bonded conical stylus
Cantilever ABS with carbon
Tracking force range 2.0 to 4.0 g (3.0 g standard)
Cartridge weight 6.2 g (0.22 oz)
Headshell model AT-HS6
Headshell weight 9 g (0.32 oz) (including lead wire)
Headshell overhang
adjustment
± 5 mm
General specifications
Power supply requirements 115 to 230 V AC, 50/60 Hz
Power consumption 6 W
Dimensions 452.0 mm (17.80") × 352.0 mm
(13.86") × 158.6 mm (6.24")
(W × D × H)
Weight 10.0 kg (22.0 lbs) (without dust
cover)
Accessories Dust cover, Felt mat, Platter,
Counterweight, Headshell (AT-HS6)
with VM stereo cartridge (AT-XP3),
45-RPM adapter, Dust cover hinges,
RCA audio cable (approx. 1.4 m
(4.6')), Power cable
Replacement stylus (sold
separately)
ATN-XP3
Replacement headshell (sold
separately)
AT-HS6
Specifications are subject to change without notice due to
improvements.
