Turntable Specifications
Type 3-Speed, fully manual operation
Motor DC motor
Drive Method Direct drive
Speeds 33-1/3 RPM, 45 RPM, 78 RPM
Pitch Variation +/- 10% or +/- 20%
Turntable Platter Die-cast aluminum
Starting Torque >1.6 kgm-cm
Braking System Electronic brake
Wow and Flutter < 0.2% WRMS (33 RPM)
Signal-to-Noise Ratio > 50 dB
Output Level
Pre-amp “Off” 2.5 mV nominal at 1 KHz, 5 cm/sec
Pre-amp “On” 200 mV nominal at 1 KHz, 5 cm/sec
Phono Pre-amp Gain 38 dB nominal, RIAA equalized
Pitch Output Output signal to drive remote pitch indicator
2.5V square wave signal
675 Hz +/- 1 Hz for 33 and 45 RPM quartz
locked speeds
Varies from 540 Hz - 810 Hz when +/- 20%
pitch is selected
Varies from 607 Hz - 742 Hz when +/- 10%
pitch is selected
1170 +/- 1 Hz for 78 RPM
Remote Start/Stop 2 conductor
1
/
4
" connector (T/S)
Normally open contact closure
Power Supply Requirements 115/230V AC, 50/60 Hz
Power Consumption 13W
Dimensions 17
3
/
4
" (450 mm) W x 13
7
/
8
" (352 mm) D
x 6" (157 mm) H
Weight 23.4 lb (10.6 kg)
Accessories Included Headshell/cartridge (ATP-2)
AC line cord
45 RPM adapter
Operation manual
Specifications
†
Cartridge Specifications (ATP-2)
Frequency Response 15-22,000 Hz
Channel Separation 23/17 (dB at 1 kHz/10 kHz)
Vertical Tracking Force 3.0 – 5.0 grams
Stylus Construction Bonded round shank
Output 5.3 mV at 1 kHz, 5 cm/sec
Channel Balance 1.5 dB
Stylus Shape 0.4 x 0.7 mil elliptical
Cantilever Alloy tube
Mount Half-inch
† Specifications are subject to change without notice.
