Audio Technica ATH-M20xBT User Manual

21
Forced pairing mode / reset
If the product does not connect to a device (forced pairing
mode)
If pairing cannot be cancelled or is not successful, you can use forced pairing mode to perform pairing again.
1
With the product turned on, press and hold (about 6 seconds) the volume buttons (+/–) at the same
time.
The product will switch to the “searching for devices” (pairing mode) state and you will be able to
pair with your desired Bluetooth device.
If the product operates abnormally (reset)
Reset the product.
1
With the product turned on, press and hold (about 6 seconds) the volume buttons (+/–) at the same
time.
2
Make sure the indicator lamp is flashing rapidly in white, and press and hold the power supply /
control button and the volume up button (+) at the same time (for about 6 seconds).
The indicator lamp will light in pink, and after the product restarts, reset is complete.
3
Remove the product from the list of registered devices on your Bluetooth device.
4
Pair the product again.

Audio Technica ATH-M20xBT Specifications

General

Product type	Headset
Product color	Black
Wearing style	Head-band
Control unit type	On-ear control unit
Recommended usage	Music
Microphone type	Built-in
Microphone frequency	50 - 20000 Hz
Microphone sensitivity	-42 dB
Microphone direction type	Omnidirectional
Impedance	36 Ω
Driver unit	40 mm
Ear coupling	Supraaural
Maximum input power	100 mW
Battery type	Built-in battery
Battery voltage	3.7 V
Battery operated	Yes
Battery recharge time	4 h
Continuous audio playback time	60 h
Operating temperature (T-T)	5 - 40 °C
Quantity	1
Cables included	Audio (3.5mm), USB Type-A to USB Type-C
Bluetooth version	5.0
Bluetooth profiles	A2DP, AAC, AVRCP, HFP, HSP, SBC
Connectivity technology	Wired & Wireless

Weight and Dimensions

Weight	216 g
