Audio Technica ATH-M20xBT User Manual

24
Specifications
Headphones
Type
Closed-back dynamic
Driver
40 mm
Sensitivity
100 dB/mW
Frequency response
5 to 32,000 Hz
Impedance
36 ohms
Microphone
Type
Electret condenser
Polar pattern
Omnidirectional
Sensitivity
-42 dB (1 V/Pa, at 1 kHz)
Frequency response
50 to 20,000 Hz
Communication specifications
Communication system
Bluetooth version 5.0
Maximum RF output
10 mW EIRP
Maximum communication
range
Line of sight - approx. 10 m (33')
Frequency band
2.402 GHz to 2.480 GHz
Modulation method
GFSK, Pi/4DQPSK, 8DPSK
Spread spectrum method
FHSS
Compatible Bluetooth profiles
A2DP, AVRCP, HFP, HSP
Supported codec
AAC, SBC
Supported content protection
method
SCMS-T
Transmission band
20 to 20,000 Hz

Audio Technica ATH-M20xBT Specifications

General

Product type	Headset
Product color	Black
Wearing style	Head-band
Control unit type	On-ear control unit
Recommended usage	Music
Microphone type	Built-in
Microphone frequency	50 - 20000 Hz
Microphone sensitivity	-42 dB
Microphone direction type	Omnidirectional
Impedance	36 Ω
Driver unit	40 mm
Ear coupling	Supraaural
Maximum input power	100 mW
Battery type	Built-in battery
Battery voltage	3.7 V
Battery operated	Yes
Battery recharge time	4 h
Continuous audio playback time	60 h
Operating temperature (T-T)	5 - 40 °C
Quantity	1
Cables included	Audio (3.5mm), USB Type-A to USB Type-C
Bluetooth version	5.0
Bluetooth profiles	A2DP, AAC, AVRCP, HFP, HSP, SBC
Connectivity technology	Wired & Wireless

Weight and Dimensions

Weight	216 g
