4
Part names and functions
Accessories
• Cable (1.2 m (3.9')/3.5 mm (1/8")
gold-plated stereo mini-plug,
L-shaped)
• USB charging cable
(30 cm (12"))
Earpad
Indicator lamp
Displays the operating status and battery level of
the product.
Jog switch
Used to adjust the volume, play
or pause music and videos, and
do phone call operations.
Connector jack
Used to connect the included cable
and use the playthrough function.
Battery jack
Used to connect the included USB
charging cable to charge the product.
L/R (left/right)
indicator
Headband
Slider
Arm
Joint
Housing
A built-in microphone is
integrated into the L (left)
housing.
Power switch
Turns the power on and off.
To Next Page
